Multi-play equipment Emerald
BBPE114.0BR
The Combination equipment "Emerald" offers several climbing routes with increasing levels of difficulty, challenging children to push their limits. The steep slide, which reaches as high as three metres, offers a spectacular descent for the real daredevils. Thanks to its adventurous nature, extensive play options and eco-friendly design, the Emerald is a favourite with youngsters!
MSRP:On requestAssembly price:On requestprices are exclusive of VAT and any assembly and transport costs (FCA Nieuwendijk, NL)
In winkelmand
Product information
| Age | 4 - 12 |
|---|---|
| Base material | Metal (coated) |
| Play functions | Combination equipment, Sliding, Climbing |
| Fall height | 3,0 mⓘ |
| Dimensions | 6,1 x 5,3 x 5,0 m |
| Fall zone | 9,6 x 9,1 m |
| Obstacle-free zone | 9,6 x 9,1 m |
| Approval authority |  |
Placement information
| Number of technicians | 2 |
|---|---|
| Beton | 0.2 m³ |
| Heaviest part | 160 kg |
| Biggest part | 3,5 x 4,5 x 0,9 m |
Related products
| Fall height | Grass ** | Pavement (concrete, asphalt, etc.) | Rubber Cast floor | EPDM Tiles | Doorgroeitegels | Artificial grass | Tiger Mulch® | Sand *** | Wood chips/ Dekowood *** | Bark *** |
|---|---|---|---|---|---|---|---|---|---|---|
| < 0,6 m | ja | ja * | 40 mm | 45 mm | 45 mm | T-25 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,0 m | ja | x | 40 mm | 45 mm | 45 mm | T-25 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,2 m | ja | x | 40 mm | 45 mm | 45 mm | T-25 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,3 m | ja | x | 60 mm | 45 mm | 45 mm | T-25 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,5 m | ja | x | 60 mm | 45 mm | 45 mm | T-35 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,6 m | x | x | 60 mm | 45 mm + 20 mm foam | 65 mm | T-35 | TM-50 | 300 mm | 300 mm | 300 mm |
| < 1,7 m | x | x | 80 mm | 45 mm + 20 mm foam | 65 mm | T-35 | TM-75 | 300 mm | 300 mm | 300 mm |
| < 1,8 m | x | x | 80 mm | 45 mm + 20 mm foam | 65 mm | T-45 | TM-75 | 300 mm | 300 mm | 300 mm |
| < 1,9 m | x | x | 80 mm | 45 mm + 20 mm foam | 65 mm | T-45 | TM-75 | 300 mm | 300 mm | 300 mm |
| < 2,0 m | x | x | 80 mm | 45 mm + 45 mm foam | 65 mm | T-45 | TM-75 | 300 mm | 300 mm | 300 mm |
| < 2,1 m | x | x | 80 mm | 45 mm + 45 mm foam | 65 mm | T-45 | TM-95 | 310 mm | 310 mm | 310 mm |
| < 2,2 m | x | x | 100 mm | 45 mm + 45 mm foam | x | T-55 | TM-95 | 320 mm | 320 mm | 320 mm |
| < 2,4 m | x | x | 100 mm | 45 mm + 45 mm foam | x | T-55 | TM-95 | 340 mm | 340 mm | 340 mm |
| < 2,7 m | x | x | 120 mm | 45 mm + 45 mm foam | x | T-70 | TM-95 | 370 mm | 370 mm | 370 mm |
| < 2,8 m | x | x | 140 mm | 45 mm + 45 mm foam | x | T-90 | x | 380 mm | 380 mm | 380 mm |
| < 3,0 m | x | x | 140 mm | x | x | T-90 | x | 400 mm | 400 mm | 400 mm |
* If there is a forced movement, a hard surface is excluded and fall damping is necessary for at least 1.0 m fall height. Spring elements are not allowed on pavement.
** Provided the surface is free of pebbles and debris.
*** Provided of sufficiently equal grain size.
